LANCOM 1781EW+

Secure site connectivity combined with Wi-Fi

Offering IPSec VPN functionality and fast Internet via external modems, this router is the right choice for small and medium-sized businesses. Be it secure VPN site connectivity for stores, offices, and home offices, or providing a wireless network, the 1781EW+ offers a wide range of options. Wireless LAN based on IEEE 802.11n (Wi-Fi 4) enables data rates of up to 450 Mbps and provides quick, flexible, and secure connections for employees and guests with mobile devices. An ISDN interface also allows it to operate with available ISDN components

Technical features

  • Versatile business VPN router for high-speed Internet via external modems
  • Wi-Fi based on IEEE 802.11n for up to 450 Mbps
  • Secure site connectivity with 5 simultaneous IPSec VPN connections (25 channels optional)
  • Integrated stateful-inspection firewall with intrusion detection and Denial-of-Service protection
  • Network virtualization with up to 16 networks on one device (ARF)
  • Gigabit routing performance thanks to the support of hardware NAT
  • Security Made in Germany
  • Maximum future compatibility, reliability, and security

Advantages

High-speed Internet via external modems

The LANCOM 1781EW+ is a high-performance VPN router for connection to an external modem by means of its Gigabit Ethernet port. This forms the basis for high-speed Internet access at retail stores, offices, and home offices.

Wi-Fi based on IEEE 802.11n

Featuring IEEE 802.11n Wi-Fi, the LANCOM 1780EW+ provides wireless networking to clients in the 2.4- or 5-GHz frequency range at speeds of up to 450 Mbps. Secure wireless LAN with the LANCOM 1780EW+ is assured by its wide range of supported security standards, including IEEE 802.1i (WPA2) and IEEE 802.1X. Thanks to multi-SSID, the wireless LAN also supports multiple networks that are securely separated from one another.

Secure site connectivity via VPN

The LANCOM 1780EW+ offers high levels of security. The standard equipment of 5 IPSec VPN channels guarantees strong encryption, secure connections for mobile employees, and protection of corporate data. The LANCOM VPN option upgrades the router to support 25 VPN channels. This ensures that your network is perfectly scalable and can grow on demand—without additional hardware components.

Stateful inspection firewall

Equipped with a stateful inspection firewall, the LANCOM 1780EW+ protects the entire network. With features such as intrusion prevention and Denial-of-Service protection, this business VPN router provides optimal protection and secures all of the data on the network.

Advanced Routing & Forwarding

The LANCOM 1780EW+ provides up to 16 securely isolated IP contexts, each of which has its own separate routing. This is an elegant way of operating IP applications with one central router and keeping the different communication channels securely separated from one another.

Security Made in Germany

Software development, hardware development and production take place primarily in Germany, as does the hosting of the network management. Special attention is given to providing trusted solutions with outstanding security features. Another important security characteristic of the products is that they are free from backdoors, as awarded by the German Federal Ministry of Economy with the quality seal “IT Security made in Germany”.

Maximum future-proofing

LANCOM products are based on professional expertise, years of experience in IT, and high-quality materials. All of our devices are equipped with hardware that is dimensioned for the future and, even reaching back to older product generations, updates to the LANCOM Operating System family are available several times a year, free of charge. This guarantees a long service life while staying technically up to date, which represents a true protection of your investment.

Systematic networking solutions

LANCOM VPN routers are the basis for secure encrypted site connectivity and high-speed Internet access. As professional system components, they are fully compatible to all LANCOM network components and enable flexible scaling and expansion when using further LANCOM components. The result is a secure and flexible all-round solution that you can rely on. The overall network down to each individual device can be managed and monitored from a central instance—for a solution that is systematic.

Further information & news

LANCOM SD-WAN

Your SD-WAN-ready LANCOM device is just the beginning on your path to highly scalable, efficient and secure networking of distributed corporate sites. Let yourself be inspired by our unique solution on the market!

The unbeatable benefits of LANCOM SD-WAN

Accessories & options

Service & support

Included services

check icon3 years hardware warranty within the EU

check iconFree technical support for end customers with valid warranty directly from LANCOM

check iconFree technical support for LANcommunity partners with valid warranty directly from LANCOM*

Charged warranty extension to 5 years is optionally available.

Optional services**

LANCOM Warranty Advanced Option

Warranty extension to 5 years within the EU with next business day

(NBD) advance replacement in case of defect and extension with security

updates until the End of Life status of the device as an option per device

S: 10715, M: 10716

L: 10717, XL: 10718

LANCOM Warranty Basic Option

Warranty extension to 5 years within the EU and extension with security

updates until the End of Life status of the device as an option per device

S: 10710, M: 10711

L: 10712, XL: 10713

LANCOM MSP-Care 24/7

Extended manufacturer support incl. 24/7 emergency hotline for projects

Availability: 24h / 7d

(on request)

LANCOM Premium Support Access

Extended manufacturer support for projects

Availability: 10h / 5d

(on request)

* Availability: 8-10h / 5d, response time: 4h-1d (depending on partner level)
** Notes: Times are given in hours (h) per days (d). The options are available for different service categories (S, M, L, XL) and can be easily added using the article numbers.
The service category of each LANCOM device can be found in the LANCOM price list.
