LANCOM LN-1702
  • LANCOM LN-1702

LANCOM LN-1702

Dual-radio enterprise-class 11ac Wave 2
Wi-Fi access point with up to 1733 Mbps
– 100% Cloud-ready

The LANCOM LN-1702 is a high-performance 11ac Wi-Fi Wave 2 enterprise access point. Based on the Wi-Fi standard IEEE 802.11ac Wave 2, this device significantly increases the efficiency of any wireless network. Featuring Multi-User MIMO, it allows all of the available streams to be used by several clients at the same time. The clients also benefit from beamforming for a better signal. The LANCOM LN-1702 provides fast Wi-Fi to 11n-clients in the 2.4-GHz frequency band as well as the growing number of 11ac-enabled devices in the 5-GHz band. On top of that, the access point can be versatilely operated: it can be orchestrated via the LANCOM Management Cloud, centrally managed by a WLAN controller or operated as a stand-alone device.

Presales Contact     Where to buy?

Wave 2

IEEE 802.11ac Wave 2, wifi infrastructure



The second generation of the IEEE 802.11ac Wi-Fi standard is called Wave 2. You can find more information about its advantages and options in our Technology section.

Advantages

Dual concurrent Wi-Fi with up to 1733 Mbps

The LANCOM LN-1702 features two Wi-Fi radio modules, one offering IEEE 802.11ac Wave 2 and the other offering IEEE 802.11n. This provides fast Wi-Fi to 11n-clients in the 2.4-GHz frequency band and also the growing number of modern 11ac-enabled devices in the 5-GHz band.

4x4 Multi-User MIMO

Multi-User MIMO (MU-MIMO for short) simultaneously distributes all of the available spatial streams of the LANCOM LN-1702 between several different Wave 2 clients, rather than one after the other as was formerly the case. The available bandwidth is used efficiently and delays in the wireless network are substantially reduced.

Beamforming

The LANCOM LN-1702 uses beamforming to actively steer the signal to the clients and minimize interfering radio signals for other clients. In combination with MU-MIMO, the clients receive dedicated spatial streams with a minimum of interference, which positively influences the data rates for all of the clients.

160 MHz Bandwith

Increasing the channel width from 80 to 160 MHz doubles the performance for Wave 2 clients. By optimizing the use of the radio spectrum, a client can be supplied with a data rate of up to 1733 Mbps.

Active Radio Control for dynamic radio-field optimization

The LANCOM LN-1702 supports the WLAN optimization feature LANCOM Active Radio Control. This intelligent combination of innovative features included with the LCOS operating system - such as Band Steering, Adaptive Noise Immunity, Adaptive RF Optimization, Airtime Fairness and Client Steering - sustainably increases WLAN performance and supports administrators with professional tools for WLAN management.

Powerful WLAN diagnostics with Spectral Scan

The Spectral Scan function enables the LANCOM LN-1702 to search its radio field for interference sources, so providing a professional tool for efficient WLAN troubleshooting. By scanning the entire frequency spectrum, sources of interference in the radio field can be identified and displayed graphically.

Security for wireless networks

With numerous integrated security features, such as IEEE 802.1X, this enterprise-class access point provides optimal security for networks. Administrators and employees alike benefit from professional security policies on the network.

Operation via LANCOM Management Cloud, WLAN controller or stand-alone

The LANCOM LN-1702 can be versatilely operated: Managed via the LANCOM Management Cloud it is integrated into a comprehensive, automized network orchestration, based on Software-defined Networking technology. It can also be operated via a LANCOM WLAN controller or be applied in stand-alone oparation.

Layer-7 application detection

Knowing what the bandwidth in your network is actually being used for can be crucial in any industry. Layer-7 application detection gives you a completely transparent overview. This means that the user-friendly LANCOM Management Cloud delivers clear and professional insight into exactly which applications (such as YouTube, Netflix, etc.) are operating anywhere on the network - true added value for all-round network monitoring.

Elegant LANCOM design with external antennas

The white LANCOM LN-1702 with external antennas has a fascinating, puristic elegance. Its modern design is ideal for operation in any industry as it blends seamlessly into any environment. It also has connectors for external antennas for maximum flexibility and tailor-made Wi-Fi coverage, whatever your needs.

Cloud ready!

This product is 100 % Cloud-ready – start with it into the new era of Hyper Integration! Learn everything about the resulting benefits in our whitepaper. Cloud management & Software-defined networking

Technical features

  • Dual concurrent Wi-Fi – parallel operation at 2.4 and 5 GHz with up to 1733 Mbps with IEEE 802.11ac Wave 2 and 450 Mbps with IEEE 802.11n
  • 4x4 Multi-User MIMO for simultaneous beam-steering for multiple clients
  • Beamforming steers the signal towards the Wi-Fi clients
  • Supports 160-MHz channel width
  • Dynamic WLAN optimization thanks to LANCOM Active Radio Control (ARC)
  • Powerful WLAN diagnostics with Spectral Scan
  • Professional security features such as IEEE 802.1X
  • SD-WLAN – automatic WLAN configuration via the LANCOM Management Cloud
  • Integrated layer-7 application detection
  • Elegant LANCOM design with external antennas

Accessories and options

Connectors
