For large installations with a large number of network components, which are required without complicated elctrical installations, this fully managed switch is perfectly suited. Featuring Power over Ethernet support on all 48 Gigabit Ethernet ports, 4 SFP+ ports, and basic layer-3 features such as static routing and DHCP, this switch offers intelligent management and numerous security features. Orchestrated via the LANCOM Management Cloud and SD-LAN, the configuration is dynamic, automated, and efficient.
- Fully managed access switch with 48x Gigabit Ethernet ports and 4x SFP+
- Basic layer 3 features like static routing and DHCP server
- IEEE 802.3af/at PoE support with 740W for efficient power supply of connected devices
- Energy saving function according to IEEE 802.3az - Port shutdown, if no data is transmitted
- Security through configurable access control on all ports according to IEEE 802.1X
The LANCOM GS-3152X is equipped with 48 Gigabit Ethernet ports and 4 SFP+ ports supporting transfer rates of up to 10 Gbps. In addition, with a data throughput of 176 Gbps on the backplane, it offers full performance even at high workload. This makes the Access switch the powerful foundation for modern network infrastructures in all industries and applications.
The LANCOM GS-3152XP supports the basic layer-3 feature static routing and thus the shift of certain routing tasks from the router to the switch. Administrator-predefined network routes, through one or multiple network segments, enable fast data transfer especially in scenarios with high data volumes and relieve the router accordingly. Newly available router capacities can then additionally be used to manage external data traffic. As a result, the entire network efficiency is increased.
As a DHCP server, the switch is able to independently and automatically assign IP addresses to clients. The LANCOM GS-3152X supports this basic layer-3 function and thus takes over the IP management of the connected network.
The LANCOM GS-3152XP is a high-performance PoE switch that directly powers PoE devices connected to it: there is no need of additional power supply units or cabling. It supports the Power over Ethernet standards IEEE 802.3af and IEEE 802.3at (PoE+). Thanks to high power reserves with a total output of 740 watts, it is therefore ideal for efficient power supply of PoE terminals with high energy requirements.
Featuring Energy Efficient Ethernet technology, the LANCOM GS-3152XP provides optimun energy effciency even at fast data rates. Thanks to numerous power-saving features based on the IEEE 802.3az standard, Ports that are not transferring data are switched off automatically. This valuable features saves precious resources.
The LANCOM GS-3152XP excludes rogue clients from gaining unauthorized access to the network. This is ensured by secured access control on all ports as per IEEE 802.1X (port-based, single-based, multi-based, and MAC-based).
Secure communication protocols such as SSH, SSL and SNMPv3 make the LANCOM GS-3152XP ideal for professional remote network management. The switch also support the TACACS+ protocol for authentication, authorization, and accounting. This optimized solution promises maximum security for multi-site network management and monitoring.
The LANCOM GS-3152XP offers fast and easy network integration and automatic configuration assignment with the LANCOM Management Cloud - without manual configuration. In this way, even complex networking scenarios are easy to administer. SD-LAN eliminates the need for a single device configuration for holistic network orchestration. In addition, automatic VLAN assignment to the desired switch ports is possible. The configurations can be coordinated with each other across locations and network architectures, and at the same time rolled out or updated at the click of a mouse.
Thanks to its dual-stack implementation, the LANCOM GS-3152XP operates in pure IPv4, pure IPv6 or in mixed networks. Applications such as SSL, SSH, Telnet or TFTP can continue to be operated on IPv6 networks. Supported IPv6 features includes stateless auto configuration, neighbor detection, and MLD snooping.
As a reliable basis for high-performance network infrastructures, the LANCOM switch portfolio is the first choice.
But how do the switch series differ? Find out with the help of the LANCOM Switch series comparison.
5 years hardware warranty within the EU
Free technical support for end customers with valid warranty directly from LANCOM
Free technical support for LANcommunity partners with valid warranty directly from LANCOM*
Extended manufacturer support incl. 24/7 emergency hotline with
next business day (NBD) advance replacement in case of defect for
1, 3, or 5 years as an option per device
Availability: 24h / 7d, delivery: NBD
S: 10230 / 10234 / 10238, M: 10231 / 10235 / 10239
L: 10232 / 10236 / 10240, XL: 10233 / 10237 / 10241
Extended manufacturer support with next business day (NBD) advance
replacement in case of defect for 1, 3, or 5 years as an option per device
Availability: 10h / 5d, delivery: NBD
S: 10242 / 10243 / 10244, M: 10245 / 10246 / 10247
L: 10248 / 10249 / 10250, XL: 10251 / 10252 / 10253
Warranty extension to 5 years within the EU with next business day
(NBD) advance replacement in case of defect and extension with security
updates until the End of Life status of the device as an option per device
S: 10715, M: 10716
L: 10717, XL: 10718
Extended manufacturer support incl. 24/7 emergency hotline for projects
Availability: 24h / 7d
Extended manufacturer support for projects
Availability: 10h / 5d
* Availability: 8-10h / 5d, response time: 4h-1d (depending on partner level)
** Notes: Times are given in hours (h) per days (d). The options are available for different service categories (S, M, L, XL) as well as durations (1 year / 3 years / 5 years for LANCOM Service Packs) and can be easily added using the article numbers. The service category of each LANCOM device can be found in the LANCOM price list.
