LANCOM 1800EF-5G

High-availability networking with 5G, fiber, and Ethernet

High performance and fail-safe: In company locations with data-intensive and business-critical applications, this SD-WAN gateway guarantees reliable networking thanks to its high interface diversity. It is suitable for direct connection to both modern fiber optic lines and external modems. The additionally integrated 5G modem ensures the best connection at all times in the event of a failure of the wired Internet, but also as a mobile primary access. With award-winning LANCOM IPSec VPN and SD-WAN, 5 (optionally 25) sites and mobile employees are securely interconnected.

Bearer of the IT Security Label (BSI)

Technical features

  • High-speed Internet via 5G, fiber optics (GPON and AON modules available separately) and Gigabit Ethernet for connection to external modems
  • Integrated 5G modem for low latency and high bandwidth for real-time applications (telephony, video streaming or AR)
  • SD-WAN – incl. zero-touch deployment, Auto-VPN, and Auto-VLAN via the LANCOM Management Cloud
  • 5 integrated IPSec VPN channels (25 optional)
  • Network virtualization with up to 16 networks on one device (ARF)
  • Security Made in Germany
  • Maximum future viability, reliability, and security

Highlights

High-speed Internet via fiber optics or Gigabit Ethernet

The high-performance VPN router LANCOM 1800EF-5G enables direct connection to a fiber-optic line (FTTH) via its SFP port using a separately available SFP module (GPON / AON). It also offers maximum flexibility via Gigabit Ethernet for connection to external modems. It is therefore suitable for all fields of application and industries and forms the basis for reliable, high-performance networking.

Learn more

Fully future-proof with 5G

With the 1800EF-5G, either as a mobile primary access or in active/active mode with other access types, you benefit from all the advantages of 5G technology. Low latency and high-performance use of real-time applications such as telephony, video chat, video streaming in 4K or 8K or augmented reality, even with a high user density, are possible.

Learn more

LANCOM SD-WAN – Next-level networking

With LANCOM SD-WAN you can manage and monitor your entire corporate network centrally, cost-effectively, quickly, and stress-free! In combination with the LANCOM Management Cloud, the SD-WAN gateway gives you all the options for an automated setup of secure VPN connections (Auto-VPN) between sites, including network virtualization. Highlight features such as High Scalability VPN (HSVPN) and Advanced Mesh VPN offer you a significant plus in scalability and efficiency for a large number of branches and applications. Furthermore, if multiple WAN connections are defined, they are automatically operated in active/active mode (load balancing), thereby increasing the available total bandwidth. With Dynamic Path Selection and Dynamic Traffic Steering, applications are also dynamically routed via the best connection at any given time.

Learn more

More advantages

Secure communication via VPN

With virtual private networks (VPN), you use the public medium of the Internet as a communication path and secure the connection in such a way that the communication still remains completely inaccessible to external parties. This SD-WAN gateway…

With virtual private networks (VPN), you use the public medium of the Internet as a communication path and secure the connection in such a way that the communication still remains completely inaccessible to external parties. This SD-WAN gateway offers you five integrated IPSec VPN channels for secure encryption, so that the protection of internal company data is always guaranteed when connecting mobile employees, home offices, or branch offices. With the LANCOM VPN Option, you can also upgrade the device to up to 25 VPN channels, so that the infrastructure can easily grow with your needs without additional hardware.

Advanced Routing & Forwarding

The LANCOM 1800EF-5G provides up to 16 securely isolated and separately routed IP contexts. This is an elegant way of routing all IP applications via a central router and securely separating the various communication…

The LANCOM 1800EF-5G provides up to 16 securely isolated and separately routed IP contexts. This is an elegant way of routing all IP applications via a central router and securely separating the various communication channels.



Techpaper: Advanced Routing & Forwarding

Stateful Inspection Firewall

Equipped with a stateful inspection firewall, the LANCOM 1800EF-5G protects the entire network. With functions such as intrusion prevention and denial of service protection, this device ensures optimum protection so that…

Equipped with a stateful inspection firewall, the LANCOM 1800EF-5G protects the entire network. With functions such as intrusion prevention and denial of service protection, this device ensures optimum protection so that all data in the network is safe.

Security Made in Germany

Software and hardware development at LANCOM Systems as well as production take place mainly in Germany, as does the hosting of the network management. Particular attention is paid to…

Software and hardware development at LANCOM Systems as well as production take place mainly in Germany, as does the hosting of the network management. Particular attention is paid to trustworthiness and security. The company is committed to ensuring that its products are free of backdoors and is a bearer of the "IT Security Made in Germany" quality mark initiated by the German Federal Ministry of Economics.

Maximum future proofing

All LANCOM products are based on professional know-how, many years of IT experience, and high-quality materials. As a matter of principle, all devices are equipped with future-proof hardware dimensioning, and even across…

All LANCOM products are based on professional know-how, many years of IT experience, and high-quality materials. As a matter of principle, all devices are equipped with future-proof hardware dimensioning, and even across product generations, updates to the LANCOM Operating Systems family are available several times a year free of charge. This guarantees many years of use at the latest technical level and thus offers genuine investment protection. In addition, LANCOM infrastructures are easily scalable. Thanks to maximum compatibility, networks can easily be expanded to include additional LANCOM components.



Connectors

Typical application scenarios

Application scenario 1: 5G and fiber

A client is connected to the Internet via the LANCOM 1800EF-5G in active/active mode (load balancing). Load balancing is used to distribute network data traffic evenly between Internet connections that are operated in parallel. In this way, data connections are divided evenly between (at least) two lines, and the individual bandwidths of the lines are combined. In this scenario, the load balancer integrated in the SD-WAN gateway decides for Internet line 1 (5G) or Internet line 2 (fiber), depending on the load. Even if one line fails, the connection is always secured via the other line.

Application scenario 2: primary access via 5G

The 5G modem integrated in the LANCOM 1800EF-5G is not only suitable for intelligent backup scenarios or parallel operation, but can also be used for 4G/5G primary operation. 5G offers fast and flexible Internet with data rates in the Gigabit range without the complex installation of wired Internet lines. This means that real-time applications such as video streaming or augmented reality (AR) can also be used with 5G mobile communications in combination with lowest latencies.

Application scenario 3: VPN load balancing

The integrated load balancer makes it easy to bundle multiple IKEv2 VPN connections into a load-balancing cluster. Be it in combination with a LANCOM SD-WAN gateway, a LANCOM SD-WAN central site gateway (e.g. LANCOM ISG-5000 in this case), or the LANCOM vRouter – the load of data traffic is more evenly balanced and the data traffic will be distributed if one connection fails. This significantly increases the VPN bandwidth available for multiple clients.


Further information & news

Bearer of the IT Security Label (BSI)

The LANCOM 1800EF-5G meets the strict security requirements of the German Federal Office for Information Security (BSI) and bears the IT Security Label.

The IT Security Label gives end users the opportunity to inform themselves about security functionalities assured by manufacturers for networked, Internet-enabled products and services.

More about the BSI IT Security Label

Site networking with LANCOM SD-WAN

Improved network availability, higher bandwidths, and maximum data security – the demands on companies are constantly growing. Services must be available in the same quality at all locations at all times. With your SD-WAN-capable LANCOM device, you have already taken the first step on the path to highly scalable, efficient, and secure networking of distributed corporate sites. In combination with the LANCOM Management Cloud, this gives you a solution that is unique on the market.

We show you the unbeatable benefits for LANCOM SD-WAN in our SD-WAN video or on the topic web page:

Learn more about LANCOM SD-WAN

5G for maximum availability

The fifth generation in mobile communications is the forward-looking successor to 4G (LTE) and uses the radio interface New Radio (NR). With best bandwidths, 5G ensures high-performance use of real-time applications such as video streaming or augmented reality. With currently unsurpassed speed at lowest latencies, the 5G standard is ideal for environments with a high user density.

Learn more about 5G

Options & accessoires

Service & support

Included services

  • 3 years hardware warranty
  • Free technical support for end customers with valid warranty directly from LANCOM
  • Free technical support for LANcommunity partners with valid warranty directly from LANCOM (availability: 8-10h / 5d, response time: 4h-1d (depending on partner level))

Charged warranty extension to 5 years is optionally available.

Optional services

Click below to get more information on these service & support products as well as the item numbers for convenient additional booking.

Click below to get more information on these service & support products as well as the item numbers for convenient additional booking.



Notes: Times are given in hours (h) per days (d). The options are available for different service categories (S, M, L, XL) and can be easily added using the item numbers. The service category of each LANCOM device can be found in the LANCOM price list.



  • LANcare Advanced
    Service package per device with security updates and support entitlement (support access required) until EOL (min. 5 years), 5 years advance replacement with delivery of the replacement device within one business day
    Availability: 8h / 5d, delivery: NBD
    Item numbers: S: 10730, M: 10731, L: 10732, XL: 10733
  • LANcare Basic
    Service package per device with security updates and support entitlement (support access required) until EOL (min. 5 years), 5 years replacement service with shipment of the replacement device within 5 days
    Availability: 8h / 5d, shipment: 5 days
    Item numbers: S: 10720, M: 10721, L: 10722, XL: 10723
  • LANCOM MSP-Care 24/7
    Extended manufacturer support incl. 24/7 emergency hotline for projects
    Availability: 24h / 7d
    (on request)
