LANCOM XS-3510YUP

10G multi-Gigabit PoE++ access switch for small scenarios

With the LANCOM XS-3510YUP, you can reliably integrate network components with high power and performance requirements, such as Wi-Fi 7 access points, into your network in smaller infrastructures.Four 1 Gigabit Ethernet and 10 multi-Gigabit Ethernet ports with Power over Ethernet (PoE+ resp. PoE++) are available for networking up to eight PoE-capable end devices without additional electrical installation. Two additional SFP28 uplink ports enable fast and future-proof uplink speeds of up to 25 Gbps. This 10-port multi-Gigabit access switch offers basic layer 3 functions, such as static routing and DHCP server, and numerous security functions, such as configurable access controls in accordance with IEEE 802.1X. Depending on your preference, you can switch between the management options web-based GUI, CLI, or the LANCOM Management Cloud (LMC) for centralized, automated network management.

Technical features

  • Multi-Gigabit access switch with 4x 1 Gigabit Ethernet ports, 4x 10G multi-Gigabit Ethernet ports, and 2x 25G SFP28 uplink ports
  • PoE support as per IEEE 802.3at (1G ports) and IEEE 802.3bt PD-Type 4 (10G ports) with up to 370 watts PoE budget
  • Non-stop PoE function – continuous supply of connected PoE devices in the event of a software update
  • IEEE 802.3az power saving feature – port deactivation when not transferring data
  • Ideal in combination with Wi-Fi 7 access points
  • Basic layer 3 features such as static routing and DHCP server
  • Security with configurable access control on all ports as per IEEE 802.1X and access control lists
  • Secure remote management through TACACS+, SSH, SSL, and SNMPv3
  • Cloud-managed LAN for fast configuration and convenient management via the LMC
  • IPv6 and IPv4 support for modern enterprise networks
  • 5-year replacement service for all components

Highlights

High performance on 10 ports

The LANCOM XS-3510YUP is equipped with 4x 1 Gigabit PoE+ Ethernet ports, 4x 10G multi-Gigabit PoE++ Ethernet ports, and 2x SFP28 fiber-optic ports that support transfer rates of up to 25 Gbps. With the SFP28 ports, you can continue to use your existing fiber optics infrastructure while benefiting from higher bandwidths per port at the same time. This means that fewer hardware purchases are required in the long term, which reduces your investment costs (CapEx). With a data throughput of 188 Gbps on the backplane, the switch offers wirespeed performance even at high workloads. The multi-Gigabit access switch thus forms the powerful basis for modern network infrastructures in all industries and areas of application.

A high-performance basis for Wi-Fi 7

Thanks to four high-performance 10G multi-Gigabit Ethernet ports, the PoE switch LANCOM XS-3510YUP is the suitable LAN-side basis for integrating Wi-Fi 7 into modern infrastructures. This is because Wi-Fi 7 access points or other network components with high transmission speeds and energy requirements mean increased performance requirements at the access level that exceed simple Gigabit Ethernet. To ensure the full performance and range of 10G, cables with higher specifications such as CAT6a or CAT7 are required.

Get to know more about Wi-Fi 7

Central power supply without additional electrical installation

As a high-performance PoE switch, the LANCOM XS-3510YUP supplies connected PoE end devices without additional power supplies or power cabling. It supports the Power over Ethernet standards IEEE 802.3at (PoE+) and IEEE 802.3bt (PoE++, Type 4) with up to 90 W per port. Thanks to high power reserves with a total output of 370 watts, it is thus ideal for efficient power supply of end devices with the highest energy requirements. In addition to Wi-Fi 7 access points, this also includes end devices such as lighting tubes, touch screens, or heated cameras, which can be operated via Power over Ethernet.

Advantages

Cloud-managed LAN with port templates

With the LANCOM Management Cloud (LMC) and Cloud-managed LAN, the LANCOM XS-3510YUP offers quick and easy network integration as well as automatic provision of the configuration across locations with…

With the LANCOM Management Cloud (LMC) and Cloud-managed LAN, the LANCOM XS-3510YUP offers quick and easy network integration as well as automatic provision of the configuration across locations with the a click of a mouse. Time-consuming individual device and switch port configurations are now a matter of the past. The targeted switch rollout via the LMC enables automatic VLAN assignment to switch ports including practical switch port profiles and therefore “zero-touch” assignment to the devices.

Secure Terminal Access provides access to the command line of the LANCOM switch (“CLI tunneling”) directly from the LANCOM Management Cloud – encrypted and without leaving the cloud interface. Secure Terminal Access provides expert functions as well as extensive diagnostic and troubleshooting commands for the devices. Some highlights include: “trace” and “ping” commands for quick troubleshooting, access to low-level configuration parameters and detailed statistics of the LCOS SX operating system as well as secure remote access to third-party devices in the local network via the integrated SSH client.

Static routing for unburdened networks

The LANCOM XS-3510YUP supports the basic layer 3 feature static routing, shifting certain routing tasks from the router to the switch. The predefinition of network routes through one or more network…

The LANCOM XS-3510YUP supports the basic layer 3 feature static routing, shifting certain routing tasks from the router to the switch. The predefinition of network routes through one or more network segments enables faster data exchange, especially in the case of high internal data traffic, and leads to a relief of the router. Freed-up router capacity is then additionally available for handling external data traffic. This increases the efficiency of the entire network.

DHCP server functionality

As a DHCP server, the switch can independently and automatically assign IP addresses to clients. The LANCOM XS-3510YUP supports this basic layer 3 function and thus takes over the IP management of the connected network.

Configurable access control & secure remote management

The LANCOM XS-3510YUP stops rogue clients from gaining unauthorized access to the network. This is ensured by secured access control on all ports as per IEEE 802.1X (port-based, single, multi, and…

The LANCOM XS-3510YUP stops rogue clients from gaining unauthorized access to the network. This is ensured by secured access control on all ports as per IEEE 802.1X (port-based, single, multi, and MAC-based) or by ACLs (access control lists). Thanks to secure communication protocols such as SSH, SSL, and SNMPv3, professional remote management of the network is possible. The switch also supports the TACACS+ protocol for authentication, authorization, and accounting. This optimized solution promises maximum security for multi-site network management and monitoring.

IPv6 and IPv4 support

Thanks to its dual-stack implementation, the LANCOM XS-3510YUP can be used in pure IPv4, pure IPv6, or mixed networks. Numerous applications such as SSL, SSH, Telnet, or TFTP can thus also be run over IPv6 networks. IPv6 features such as stateless autoconfiguration, neighbor device discovery, and MLD snooping round out the IPv6 features.

Maximum future-proofing and digital sovereignty

As an established German manufacturer of IT network solutions, LANCOM stands for reliability and know-how. Software and hardware development as well as production take place primarily in Germany, as does the hosting of…

As an established German manufacturer of IT network solutions, LANCOM stands for reliability and know-how. Software and hardware development as well as production take place primarily in Germany, as does the hosting of the network management.  Special attention is given to providing trusted solutions with outstanding security features. Another important security characteristic of the products is that they are free from backdoors, as awarded by the German Federal Ministry of Economy with the quality seal “IT Security made in Germany”. All devices are always equipped with with hardware that is dimensioned for the future. Even across product generations, updates to the LANCOM operating system family are available several times a year, free of charge. his guarantees a long service life while staying technically up to date, which represents a true protection of your investment. In addition, LANCOM infrastructures are easily scalable thanks to maximum compatibility.

Learn more about digital sovereignty

Connectors

Front view LANCOM XS-3510YUP

Further information & news

Options & accessories

¹ Compatible transceiver modules: SFP-SX-LC1, SFP-SX2-LC1, SFP-LX-LC1, SFP-SX-LC10, SFP-LX-LC10, SFP-LR40-LC10, SFP-SR-LC25, SFP-LR-LC25, SFP-BiDi1550-SC1, SFP-BiDi1310-LC10, and SFP-CO10-MG (max. 1x SFP-CO10-MG per switch)

² Compatible Direct Attach Cable: SFP-DAC10-1M / -3M and SFP-DAC25-1M / -3M

Service & support

Included services

  • 5 years replacement service (return & replace)
  • Technical manufacturer support for LANcommunity partners and end customers with LANcare Direct or LANcare Premium Support

Optional services

Click below to get more information as well as the item numbers for convenient additional booking.

Click below to get more information as well as the item numbers for convenient additional booking.

Notes: Times are given in hours (h) or minutes (m) per days (d). For this switch, the products are available with different service categories (S, M, L) as well as terms and can be easily added using the item numbers.


  • LANcare Direct 10/5
    Direct manufacturer support and security updates for 1, 3, or 5 years
    Availability: 10h / 5d, first reaction time: 2h (priority 1) up to 4h (priority 2)
    Item numbers: S: 10740 / 10741 / 10742, M: 10743 / 10744 / 10745, L: 10746 / 10747 / 10748

  • LANcare Direct Advanced 10/5
    Direct manufacturer support, security updates, and advance relacement for 1, 3, or 5 years
    Availability: 10h / 5d, first reaction time: 2h (priority 1) up to 4h (priority 2), delivery: NBD
    Item numbers: S: 10764 / 10765 / 10766, M: 10767 / 10768 / 10769, L: 10770 / 10771 / 10772

  • LANcare Direct 24/7
    Direct manufacturer support incl. 24/7 emergency hotline and security updates for 1, 3, or 5 years
    Availability: 24h / 7d, first reaction time: 30m (priority 1) up to 4h (priority 2)
    Item numbers: S: 10752 / 10753 / 10754, M: 10755 / 10756 / 10757, L: 10758 / 10759 / 10760

  • LANcare Direct Advanced 24/7
    Direct manufacturer support incl. 24/7 emergency hotline, security updates, and advance relacement for 1, 3, or 5 years
    Availability: 24h / 7d, first reaction time: 30m (priority 1) up to 4h (priority 2), delivery: NBD
    Item numbers: S: 10776 / 10777 / 10778, M: 10779 / 10780 / 10781, L: 10782 / 10783 / 10784

  • LANcare Advanced
    Security updates until EOL as well as 5 years advance relacement
    Availability: 8h / 5d, delivery: NBD
    Item numbers: S: 10730, M: 10731, L: 10732

  • LANcare Premium Support 10/5
    Manufacturer support and security updates for projects
    Availability: 10h / 5d, first reaction time: 2h (priority 1) up to 4h (priority 2)
    (on request)

  • LANcare Premium Support 24/7
    Manufacturer support incl. 24/7 emergency hotline and security updates for projects
    Availability: 24h / 7d, first reaction time: 30m (priority 1) up to 4h (priority 2)
    (on request)
