LANCOM 1790-4G+

Versatile connected via LTE-Advanced or external modems

This SD-WAN gateway offers you secure VPN functionality with maximum freedom of choice regarding the Internet lines available at the site: Thus, you realize reliable Internet access with additional LTE backup via the con­nection of any external modems. If, for example, you do not have a wired Internet connection on site, the device offers professional prima­ry access via the LTE-Advanced cellular standard with up to 300 Mbps thanks to 4G.

Bearer of the IT Security Label (BSI)

Technical features

  • SD-WAN gateway with LTE/4G cellular networking for up to 300 Mbps (CAT 7)
  • Gigabit Ethernet interface for connection to external DSL or cable modems
  • SD-WAN – automatic VPN and VLAN configuration via the LANCOM Management Cloud
  • 5 simultaneous IPSec VPN connections (25 channels optional)
  • Network virtualization with up to 16 networks on one device (ARF)
  • USB 2.0 port for the integration of modern IoT radio systems
  • Security Made in Germany
  • Maximum future compatibility, reliability and security

Advantages

Maximum availability

Ideal for business critical applications: The additional LTE-Advanced Modem (Cat. 7) for fast mobile phone access with up to 300 Mbps downstream is ideal for intelligent backup scenarios or as an alternative to wired Internet connections. With an upstream rate of up to 150 MBbps, the module offers high speed data transfer within the company network or to external cloud services.

Connects external modems

Der LANCOM 1790-4G+ ermöglicht den Anschluss eines externen Modems über die Gigabit Ethernet-Schnittstelle und bietet damit größtmögliche Unabhängigkeit bezüglich der Standort verfügbaren Internetleitungen.

LANCOM SD-WAN – Next-level networking

With LANCOM SD-WAN you can manage and monitor your entire corporate network centrally, cost-effectively, quickly, and stress-free! In combination with the LANCOM Management Cloud, the SD-WAN gateway gives you all the options for an automated setup of secure VPN connections (Auto-VPN) between sites, including network virtualization. Highlight features such as High Scalability VPN (HSVPN) and Advanced Mesh VPN offer you a significant plus in scalability and efficiency for a large number of branches and applications. Furthermore, if multiple WAN connections are defined, they are automatically operated in active/active mode (load balancing), thereby increasing the available total bandwidth. With Dynamic Path Selection and Dynamic Traffic Steering, applications are also dynamically routed via the best connection at any given time.

Secure communication via VPN

With virtual private networks (VPN), you use the public medium of the Internet as a communication path and secure the connection in such a way that the communication still remains completely inaccessible to external parties. This SD-WAN gateway offers you five integrated IPSec VPN channels for secure encryption, so that the protection of internal company data is always guaranteed when connecting mobile employees, home offices, or branch offices. With the LANCOM VPN Option, you can also upgrade the device to up to 25 VPN channels, so that the infrastructure can easily grow with your needs without additional hardware.

Stateful inspection firewall

Equipped with a stateful inspection firewall, the LANCOM 1790-4G+ protects the entire network. With features such as intrusion prevention and Denial-of-Service protection, this device provides optimal protection and secures all of the data on the network.

Advanced Routing & Forwarding

The LANCOM 1790-4G+ provides up to 16 securely isolated IP contexts, each of which has its own separate routing. This is an elegant way of operating IP applications with one central router and keeping the different communication channels securely separated from one another.

IoT-ready

The aim of the IoT (“Internet of Things”) is to capture information about physical “things”, mostly by wireless, and to make it accessible over the network. The integrated USB port of the LANCOM 1790-4G+ provides you with the basis of integrating modern IoT radio systems into your existing network infrastructure.

Security Made in Germany

Software development, hardware development and production take place primarily in Germany, as does the hosting of the network management. Special attention is given to providing trusted solutions with outstanding security features. Another important security characteristic of the products is that they are free from backdoors, as awarded by the German Federal Ministry of Economy with the quality seal “IT Security made in Germany”.

Maximum future-proofing

LANCOM products are based on professional expertise, years of experience in IT, and high-quality materials. All of our devices are equipped with hardware that is dimensioned for the future and, even reaching back to older product generations, updates to the LANCOM Operating System family are available several times a year, free of charge. This guarantees a long service life while staying technically up to date, which represents a true protection of your investment.

Systematic networking solution

LANCOM VPN routers are the basis for secure encrypted site connectivity and high-speed Internet access. As professional system components, they are fully compatible to all LANCOM network devices and they facilitate flexible scaling and expansion when combined with further LANCOM components. The result is a secure and flexible all-round solution that you can rely on. The overall network down to each individual device can be managed and monitored from a central instance – for a solution that is systematic.

Connectors


Further information & news

Bearer of the IT Security Label (BSI)

The LANCOM 1790-4G+ meets the strict security requirements of the German Federal Office for Information Security (BSI) and bears the IT Security Label.

The IT Security Label gives end users the opportunity to inform themselves about security functionalities assured by manufacturers for networked, Internet-enabled products and services.

More about the BSI IT Security Label

Site networking with LANCOM SD-WAN

Improved network availability, higher bandwidths, and maximum data security – the demands on companies are constantly growing. Services must be available in the same quality at all locations at all times. With your SD-WAN-capable LANCOM device, you have already taken the first step on the path to highly scalable, efficient, and secure networking of distributed corporate sites. In combination with the LANCOM Management Cloud, this gives you a solution that is unique on the market.

We show you the unbeatable benefits for LANCOM SD-WAN in our SD-WAN video or on the topic web page:

Learn more about LANCOM SD-WAN

Options & accessories

Service & support

Included services

  • 3 years hardware warranty
  • Free technical support for end customers with valid warranty directly from LANCOM
  • Free technical support for LANcommunity partners with valid warranty directly from LANCOM (availability: 8-10h / 5d, response time: 4h-1d (depending on partner level))

Charged warranty extension to 5 years is optionally available.

Optional services

Click below to get more information on these service & support products as well as the item numbers for convenient additional booking.

Click below to get more information on these service & support products as well as the item numbers for convenient additional booking.



Notes: Times are given in hours (h) per days (d). The options are available for different service categories (S, M, L, XL) and can be easily added using the item numbers. The service category of each LANCOM device can be found in the LANCOM price list.



  • LANcare Advanced
    Service package per device with security updates and support entitlement (support access required) until EOL (min. 5 years), 5 years advance replacement with delivery of the replacement device within one business day
    Availability: 8h / 5d, delivery: NBD
    Item numbers: S: 10730, M: 10731, L: 10732, XL: 10733
  • LANcare Basic
    Service package per device with security updates and support entitlement (support access required) until EOL (min. 5 years), 5 years replacement service with shipment of the replacement device within 5 days
    Availability: 8h / 5d, shipment: 5 days
    Item numbers: S: 10720, M: 10721, L: 10722, XL: 10723
  • LANCOM MSP-Care 24/7
    Extended manufacturer support incl. 24/7 emergency hotline for projects
    Availability: 24h / 7d
    (on request)

All at a glance

Always keep track of all services and options for LANCOM hardware products with the practical Overview of the LANCOM Service & Support.
